TECHNICAL PARAMETERS
|
Item |
Main Technical Parameters |
|||
|
Model |
CPCBD50 |
|||
|
Rated lift capacity (kg) |
5000 |
|||
|
Steering type |
Rear wheel type hydraulic steering |
|||
|
Machine weight (kg) |
7500 |
|||
|
Overall size (mm) |
Total length (w/o forklift) |
3150±100 |
||
|
Total length (w/t forklift) |
4420 |
|||
|
Total width |
1580±100 |
|||
|
Mast retracted |
2190 |
|||
|
Mast extended |
4290 |
|||
|
Total height (Overhead guard) |
2300±100 |
|||
|
Wheel base (mm) |
2150±100 |
|||
|
F/R track (mm) |
1530/ 1190 |
|||
|
Ground clearance Min.(Mast) (mm) |
200 |
|||
|
Traveling speed Max.(Km/h) |
Laden |
22 |
||
|
Unladen |
18 |
|||
|
Traction power Max.(KN) |
25 |
|||
|
Brake (Service brak/Parking brake) |
Service brake |
Wet brake (hydraulic brake, spring release)
|
||
|
Parking brake |
Mechanical |
|||
|
Turning radius Min.(mm) |
Inner side |
450 |
||
|
Outer side |
3600±100
|
|||
|
Negoniable gradient Max.(%) |
14 |
|||
|
Overall maximum lift height |
2500 |
|||
|
Free lift height |
1500 |
|||
|
Fork size (LxWxT mm) |
55X150X1070 |
|||
|
Lateral Fork Adjustment Max/Min (Outside of Forks) (mm) |
300~1070 |
|||
|
Tilt of the mast,front/rear(° ) |
6/12 |
|||
|
Lifting speed (mm/s) |
370 |
|||
|
Lowering speed (mm/s) |
160 |
|||
|
Protection type |
Lightning protection |
|||
|
Explosion proof diesel engine |
XTW4105DZLDFB(A)
|
|||
|
Rated power(Kw/r/min) |
70/2200 |
|||
