TECHNICAL PARAMETERS
|
Electric Stacker Forklift Parameter |
||||||
|
|
1.1 |
Origin |
|
China |
China |
China |
|
1.2 |
Brand |
|
Kuangan |
Kuangan |
Kuangan |
|
|
1.3 |
Model |
|
KAES2000D-200 |
KAES2000D-250 |
KAES2000D-300 |
|
|
1.4 |
Power Type |
|
Battery |
Battery |
Battery |
|
|
1.5 |
Operation Type |
|
Standing Driving |
Standing Driving |
Standing Driving |
|
|
1.6 |
Load Capacity |
kg |
2000 |
2000 |
2000 |
|
|
1.7 |
Load Center |
mm |
500 |
500 |
500 |
|
|
1.8 |
Lift Height |
mm |
2000 |
2500 |
3000 |
|
|
1.9 |
Wheelbase |
mm |
1300 |
1300 |
1300 |
|
|
|
2.1 |
Overall Dimension(L×W) |
mm |
1990×800 |
1990×800 |
1990×800 |
|
2.2 |
Mast Height |
mm |
1580 |
1880 |
2180 |
|
|
2.3 |
Fork Dimension |
mm |
1080×160×60 |
1080×160×60 |
1080×160×60 |
|
|
2.4 |
Fork Width Min./Max. |
mm |
550/685 |
550/685 |
550/685 |
|
|
2.5 |
Min. Ground Clearance |
mm |
85 |
85 |
85 |
|
|
2.6 |
Turning Radius |
mm |
1410 |
1410 |
1410 |
|
|
2.7 |
Channel width ,with 1000X1200mm tray |
mm |
1580 |
1580 |
1580 |
|
|
|
3.1 |
Self Weight(with battery) |
kg |
650 |
680 |
710 |
|
3.2 |
Battery Weight |
kg |
52 |
52 |
52 |
|
|
|
4.1 |
Wheel Type |
|
Solid PU |
Solid PU |
Solid PU |
|
4.2 |
Driving Wheel Sizes |
mm |
210×70 |
210×70 |
210×70 |
|
|
4.3 |
Auxiliary wheel Sizes |
mm |
110×55 |
110×55 |
110×55 |
|
|
4.4 |
Loading Wheel Sizes |
mm |
80×70 |
80×70 |
80×70 |
|
|
4.5 |
Tread,Front |
mm |
530 |
530 |
530 |
|
|
|
5.1 |
Driving Motor |
kw(60min) |
1.5 |
1.5 |
1.5 |
|
5.2 |
Lifting Motor |
kw(60min) |
2.2 |
2.2 |
2.2 |
|
|
5.3 |
Battery Dimension |
mm |
271×174×213 |
271×174×213 |
271×174×213 |
|
|
5.4 |
Battery Voltage/Capacity |
V/ah |
24/100 |
24/100 |
24/100 |
|
|
5.5 |
Controller |
|
DC |
DC |
DC |
|
|
5.6 |
Working Pressure |
mpa |
12 |
12 |
12 |
|
|
|
6.1 |
Driving Speed |
km/h |
4/4.5 |
4/4.5 |
4/4.5 |
|
6.2 |
Lifting Speed |
mm/s |
45/55 |
45/55 |
45/55 |
|
|
6.3 |
Lowering Speed |
mm/s |
40/55 |
40/55 |
40/55 |
|
|
6.4 |
Max Climbing Ability |
% |
3 |
3 |
3 |
|
|
6.5 |
Service Braking |
|
electromagnetic induction |
electromagnetic induction |
electromagnetic induction |
|
|
6.6 |
Parking Braking |
|
electromagnetic induction |
electromagnetic induction |
electromagnetic induction |
|
|
|
7.1 |
Driving Type |
|
Electric |
Electric |
Electric |
|
7.2 |
Steering Type |
|
Manual |
Manual |
Manual |
|
|
7.3 |
Noise Level |
|
59 |
59 |
59 |
|
|
7.4 |
Waterproof Grade |
|
IP68 |
IP68 |
IP68 |
|
